ECW270 Cloud Managed Wi-Fi 6 4 x 4 Outdoor Access Point.

Dual-Band 11ax reaches speeds of 2,400 Mbps on 5 GHz and 1,200 Mbps on 2.4 GHz band

EnGenius
SKU: ECW270
MPN: 1104A0249301
Lagerstatus: På väg in
13 990 kr
Exklusive moms: 3 497,50 kr
st

Product Highlight

ECW270 Wi-Fi 6, 4x4, IP68, MU-MIMO Cloud Managed Dual-Band Outdoor Wireless Access Point reaches speeds of 2,400 Mbps on 5 GHz and 1,200 Mbps on 2.4 GHz band. This top-of-the-line cloud-managed AP features the latest in rugged weatherproofing and Wi-Fi 6 technology with guaranteed top-notch performance and reliability in the harshest environments.

  • Dual concurrent 802.11ax & backward-compatible with 11ac/a/b/g/n client devices

  • Supports up to 2,400 Mbps in 5 GHz band & 1,200 Mbps in 2.4 GHz band

  • IP68-Rated weatherproof & dustproof housing withstands harsh environments

  • 1 x 2.5 Giga PoE++ compatible port realizes greater throughput and supports Power over Ethernet (802.3 at/bt) for flexible installation over 100 meters (328 feet)

  • 1 x Gigabit Port

  • Four detachable 5 dbi high-gain 2.4GHz antennas

  • Four detachable 7 dbi high-gain 5GHz antennas

  • Quick-scan device register & configuration and remote monitoring & troubleshooting

  • Cloud manage an unlimited number of APs from anywhere with the EnGenius Cloud App

  • Mesh Wireless Support simplifies setup, optimizes signals & self-heals

Work Smart with EnGenius Cloud

Recensioner

Be the first to post a review for this product

Rate This Product

You must be logged in to rate this product
Technical Specifications
Standards
IEEE 802.11ax on 2.4 GHz
IEEE 802.11ax on 5 GHz
Backward compatible with 802.11a/b/g/n/ac
Antenna
4 x 2.4 GHz: 5 dBi (External Omni-Directional)
4 x 5 GHz: 7 dBi (External Omni-Directional)
Physical Interface
1 x 10/100/1000 Ethernet Port
1 x 10/100/1000/2500 Ethernet Port (PoE++)
LED Indicators
1 x Power
1 x LAN1
1 x LAN2
1 x 2.4 GHz
1 x 5 GHz
Power Source
Power-over-Ethernet: 802.3 at/bt Input
IEEE 802.11e Compliant Source
Active Ethernet (PoE)
Maximum Power Consumptio
46W
Wireless & Radio Specifications
Operating Frequency
Dual-Radio Concurrent 2.4 GHz & 5 GHz
Operation Modes
Managed mode: AP, AP Mesh, Mesh
Frequency Radio
2.4 GHz: 2400 MHz ~ 2483 MHz
5 GHz: 5150 MHz ~ 5250 MHz, 5250 MHz ~ 5350 MHz, 5470 MHz ~ 5725 MHz, 5725 MHz ~ 5875 MHz
Transmit Power
Up to 24 dBm on 2.4 GHz
Up to 24 dBm on 5 GHz
(Maximum power is limited by regulatory domain)
Radio Chains/Spatial Stream
4 × 4:4
SU-MIMO
Four (4) spatial stream Single User (SU) MIMO for up to 1148 Mbps wireless data rate with HE40 bandwidth to a 4×4 wireless client device under the 2.4GHz radio.
Four (4) spatial stream Single User (SU) MIMO for up to 2400 Mbps wireless data rate with HE80 to a 4×4 wireless device under the 5GHz radio.
MU-MIMO
Four (4) spatial streams Multiple (MU)-MIMO up to 2,400 Mbps wireless data rate for transmitting to four (4) streams MU-MIMO 11ax capable wireless client devices under 5GHz simultaneously.
Four (4) spatial streams Multiple (MU)-MIMO up to 1,148 Mbps wireless data rate for transmitting to four (4) streams MU-MIMO 11ax capable wireless client devices under 2.4GHz simultaneously.
Supported Data Rates (Mbps)
802.11ax
2.4 GHz: 9 to 1,148 (MCS0 to MCS11, NSS = 1 to 4)
5 GHz: 18 to 2,400 (MCS0 to MSC11, NSS = 1 to 4)
802.11b: 1, 2, 5.5, 11
802.11a/g: 6, 9, 12, 18, 36, 48, 54
802.11n: 6.5 to 600 (MCS0 to MCS31)
802.11ac: 6.5 to 1,733 (MCS0 to MCS9, NSS = 1 to 4)
Supported Radio Technologies
802.11ax: Orthogonal Frequency Division Multiple Access(OFDMA)
802.11a/g/n/ac: Orthogonal Frequency Division Multiple (OFDM)
802.11b: Direct-sequence spread-spectrum (DSSS)
Channelization
802.11ax supports high efficiency throughput (HE) —HE 20/40/80 MHz
802.11ac supports very high throughput (VHT) —VHT 20/40/80 MHz
802.11n supports high throughput (HT) —HT 20/40 MHz
802.11n supports high throughput under the 2.4GHz radio –HT40 MHz (256-QAM)
802.11n/ac/ax packet aggregation: A-MPDU, A-SPDU
Supported Modulation
802.11ax: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM, 1024-QAM
802.11ac: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM
802.11b: BPSK, QPSK, CCK
Max Concurrent User
511 Per radio
Management Features
Multiple BSSID:
8 SSIDs for both 2.4 GHz and 5 GHz radios
VLAN Tagging
Supports 802.1q SSID-to-VLAN Tagging
Cross-Band VLAN Pass-Through
Management VLAN
Spanning Tree
Supports 802.1d Spanning Tree Protocol
QoS (Quality of Service)
Complaint With IEEE 802.11e Standard
WMM
SNMP
v1, v2c, v3
MIB
I/II, Private MIB
Fast Roaming
802.11r/k
Wireless Security
WPA2-PSK
WPA2-Enterprise
WPA3-PSK
WPA3-Enterprise
Hide SSID in Beacons
MAC Address Filtering, Up to 32 MACs per SSID
Wireless STA (Client) Connected List
Https
SSH Tunnel
Client Isolation
Environmental & Physical
Temperature Range:
Operating: – -4 º~149 ºF/-20 ºC~65 ºC
Storage: -40Fº~176ºF/-40ºC~80ºC
Humidity (non-condensing)
Operating: 90% or less
Storage: 90% or less
IP Rating
IP68
Surge Protection
1KV
ESD Protection
Contact: 4KV
Air: 8 KV
Dimensions & Weight
Device ECW270
Weight: 1870g
Width: 218 mm
Length: 285 mm
Height: 53 mm
Package Contents
1 – ECW270 Cloud Managed Outdoor Access Point
2 – Mounting Brackets
1 – Wall-Mount Screw Set
4 – 2.4GHz 5dBi Detachable Antennas
4 – 5GHz 5dBi Detachable Antennas
1 – Quick Installation Guide
Certifications FCC, CE, IC
